the name that you want the totalizer to display for the
totalized units.

Process Temperature - Sets the process temperature
engineering units for the StarPac II system. Use the NEXT and
PREVIOUS function keys to select units from the following list:

ºC - Degrees Celsius

ºF - Degrees Fahrenheit

ºR - Degrees Rankine

ºK - Degrees Kelvin

Actuator Pressure - Sets the actuator pressure engineering
units for the StarPac II system. Use the NEXT and PREVIOUS
function keys to select units from the following list:

PSIG - Pounds per square-inch gauge

PSIA - Pounds per square-inch absolute

kPa G - Kilopascals gauge

kPa A - Kilopascals absolute

kgscmG - Kilograms per square-centimeter gauge

kgscmA - Kilograms per square-centimeter absolute

Bar G - Bar gauge

Bar A - Bar absolute

Tag Name - This option allows the user to enter a tagname that will
be used as an identifier for the unit on a Modbus network.

Password - This option sets up a password to control access to the
local interface. Access to the T

UNE

, C

ALIBRATE

, and C

ONFIGURE

menus is allowed only with the password after the password has
been enabled. The S

TATUS

menu is still accessible even when the

password is enabled. To enable the password, press F1 and enter
the password. The default password is “1234.” (If the system is
initialized by pressing the “0” while powering up the unit, the
password will be reset to “1234.” Note that control and
communication parameters will also be reset with an initialize.) To
disable the password, press F2. To change the password, select F3
and enter the old password, then enter the new password. Note that
when entering a new password the characters are visible on the
screen for verification.

Communication Settings - This option configures the
communication settings for the Modbus communications ports on the
StarPac II system. Both COMM port A and COMM port B use the
same settings--they cannot be set independently. The
communication settings are set in the C

OMM

ORT

menu (Figure 9).
