UT4579 X-Band Up Converter

MN/UT4579.IOM

Redundant System Operation

Rev. 0

36

IF INPUT #2

IF INPUT #1

(PRIORITY)

UP CONVERTER

(BACKUP UNIT)

RF OUTPUT #2

RF OUTPUT #1

(PRIORITY)

UP CONVERTER

Figure 25 1:1 Redundant Configuration Diagram

Dual Source IF Input with IOM-XX and TSM-XX Installed.
