• Connect the CAT 5 straight-through cable from the IPSat GW1000 Ethernet 10/100 BaseT port to a
10/100 port on a switch.
• Connect the CAT 5 crossover cable to a 10/100 port on a server, PC, or TCP Optimizer .
7 Connect an external power supply to the IPSat GW1000, if required.
• Ensure that the external power supply equipment is turned Off.
• Connect the external power supply cable, part number 05-0952-001, from the DC Power In connector
to the external power supply equipment. Then connect the external power supply equipment to an
AC outlet according to that manufacturer’s instructions.
8 Connect the IPSat GW1000 to an AC power source.
• Ensure the IPSat GW1000 power switch is in the Off, or 0, position.
• Select an AC power cord. If an international power cord is selected, attach a connector in accordance
with local regulations and laws.
• Connect the female plug of the AC power cord to the AC power receptacle on the IPSat GW1000 rear
panel.
• Connect the male plug of the AC power cord to an external AC power conditioning surge suppressor.
• Connect the AC power conditioning surge suppressor to an AC outlet.
Corrupted AC input power can interrupt IPSat GW1000 operations and cause permanent damage to the unit. You
should purchase and install a commercially available, external AC power conditioning surge suppressor to protect
the IPSat GW1000 against power spikes and line transients.
Powering On The IPSat GW1000
Once the cabling and interconnections for the IPSat GW1000 are completed, you may power-up the unit. The IPSat
GW1000 power switch is a rocker switch located on the rear panel.
The power switch is labeled with a — and an 0. The — represents the On position, while the 0 represents the Off
position.
To power up the IPSat GW1000, press the power switch to the ON, or — position. The power-on cycle takes
approximately three to four minutes to complete, as the unit performs extensive self-diagnostics in this time period.
