SDR-54A Satellite Demodulator Revision 4
Remote Control Specification MN/SDR54A.IOM
A.5 DEMUX Commands/Responses
DEMUX
Tributary
Data Rate &
Enable Command:
Response:
Status:
Response:
<1/DTDR_x_yyyyyy'cr'
>1/DTDR_x_yyyyyy'cr''lf']
<1/DTDR_x_'cr'
>1/DTDR_x_yyyyyy'cr''lf'] Where:
x = 1 to 8 (Tributary number).
yyyyyy = Off (Disabled), 0.6 to 4000.0 kbit/s for RS422, in
100 bit/s steps, or 0.6 to 64.0 kbit/s for RS232, in 100 bit/s
steps.
DEMUX
Tributary
Interface
Type Command:
Response:
Status:
Response:
<1/DTIT_x_yyyyy'cr'
>1/DTIT_x_yyyyy'cr''lf']
<1/DTIT_x_'cr'
>1/DTIT_x_yyyyy'cr''lf'] Where:
x = 1 to 8 (Tributary number).
yyyyy = RS422 or RS232.
DEMUX
Tributary
Output Map Command:
Response:
Status:
Response:
<1/DTOP_n_m'cr'
>1/DTOP_n_m'cr''lf']
<1/DTOP_n'cr'
>1/DTOP_n_m'cr''lf'] Where:
n = Tributary number (1 to 8).
m = Output number (1 to 8).
DEMUX
Tributary
Clock
Phase Command:
Response:
Status:
Response:
<1/DTCP_x_yyy'cr'
>1/DTCP_x_yyy'cr''lf']
<1/DTCP_x_'cr'
>1/DTCP_x_yyy'cr''lf'] Where:
x = 1 to 8 (Tributary number).
yyy = NRM (Normal Clock Phasing) or INV (Inverted Clock
Phasing).
DEMUX
Tributary
Data Phase Command:
Response:
Status:
Response:
<1/DTDP_x_yyy'cr'
>1/DTDP_x_yyy'cr''lf']
<1/DTDP_x_'cr'
>1/DTDP_x_yyy'cr''lf'] Where:
x = 1 to 8 (Tributary number).
yyy = NRM (Normal Data Phasing) or INV (Inverted Data
Phasing).
A–10
