Demux 8-channel (option), Description – Comtech EF Data SDR-54A User Manual
Page 41
SDR-54A Satellite Demodulator
Revision 4
DEMUX Option
MN/SDR54A.IOM
5.3
DEMUX 8-Channel (Option)
5.3.1 Description
The (AS/5839) DEMUX 8-Channel PCB, shown in Figure 5-3, is an option which plugs
into the demodulator motherboard. This DEMUX is designed to be used with the
8-Channel MUX (AS/5985) and the SDM-300/-300A Satellite Modem. The aggregate
data rate selected on the SDR-54A must include the 1.3 kbps overhead.
Figure 5-3. DEMUX 8-Channel PCB
5-7
