background image

SDR-54A Satellite Demodulator

Revision 4

Specifications

MN/SDR54A.IOM

8.4

Signal Level Indication for Antenna Pointing

The receiver provides the AGC control signal as an output to aid the user in coarse
pointing the antenna towards the satellite. The AGC control signal is provided both as an
analog signal, and as a digital value through the M&C interface (per the M&C interface
specification). The analog signal is a buffered DC output, proportional to the receive
signal level, available on the front panel M&C connector at 10 mA maximum, 0 to 5V.

For fine antenna pointing, the estimated Eb/N0 value will be used. The Eb/N0 value is
available to the host computer or terminal via the M&C interface.

8.5

Unit-to-Unit Delay Variation

The demodulator will have a unit-to-unit delay variation for rate 1/2 only, as follows
without Reed-Solomon.

Symbol Rate Range

Delay Variation

19.2k

≤ RS ≤ 800K

RS < 19.2K

1

µS

2

µS

8–8
