SDR-54A Satellite Demodulator

Revision 4

Specifications

MN/SDR54A.IOM

8.6

Monitor and Control (M&C) Specification

Refer to (Table 8-8) for M&C specifications.

Table 8-8. Monitor and Control Specifications

Parameter

Specification

Interface

Asynchronous RS-232

Connector Type

9-pin sub-D (female)

Baud Rate

9600 bps

Data Format

11 bits/characters: 7 data, 2 stop, 1 start, and 1 parity

Parity Even
Configuration Parameters:

BER Threshold
Code Rate (1/2, 3/4, or 7/8)
Data Rate
Data Inhibit
Demodulation Type
Demux Tributary Clock Phase Demux
Tributary Data Rate
Demux Tributary Data Phase
Demux Tributary Interface Type
Demux Tributary Output Mapping
Descrambler Decoder
Differential Decoder
L-Band Frequency
LNB Power Mon:
Reacquisition Time
Reed-Solomon Decoder
Reed-Solomon Deinterleaver Depth
SLRC Group Address
SLRC Individual Address
Spectral Rotation
Sweep Range
Sweep Reset


1E-3 to 1E-8 or None
QPSK or BPSK (1/2, 3/4, and 7/8)
4.8 to 4375 kbps
ON/OFF
INTELSAT Open, CEFD Closed, SDM-51
INV/NRM
600 bps to 4 Mbps
INV/NRM
RS-232 or RS-422
1 to 8
Enable
Enable
950.0 to 1550.0 MHz
Low Limit: 0 to 500 mA/High Limit: 0 to 500 mA
0 to 99 seconds
ON/OFF
8 or 16
0 to 255
0 to 65535
INV/NRM

10.0

to 1000 kHz

Stop Sweep

Non-volatile Configuration Storage

Configuration retained without prime power for at least
1 year

Fault Status

BER Threshold
Carrier Detect
Demux Module/Lock
DSP Active
FPGA Program
LNB Power
Reed-Solomon Module/Lock
RF LO Lock Detect

Monitor Status

Corrected BER
E

b

/N

0

Raw BER
Receive Frequency Offset
Receive Signal Level

System Status

DSP Firmware/ASIC Configuration Data
Equipment Type
FPGA Firmware
M&C Firmware

8–9
