SDR-54A Satellite Demodulator Revision 4
Remote Control Specification MN/SDR54A.IOM
Demodulator
Config Status Command:
Response:
<1/DCS_'cr'
>1/DCS_'cr'
DF_nnnn.nn'cr'
DR_nnnn.nnn'cr'
CR_xxxx'cr'
SR_xx'cr'
SWR_nnnnnnn'cr'
DDEC_'cr'
DE_'cr'
BERT_'cr'
DT_xxxx'cr'
RAIS_xxx'cr'
GA_xxx'cr'
LA_xxxxx'cr'
DSR_xxxx'cr'
SPL_nnn'cr'
SPH_nnn'cr'
RSDE_xxx'cr’
RRSI_'xx'cr''lf']
Demodulator Frequency
Demodulator Data Rate
Demodulator Code Rate
Sweep Reacquisition Time
Sweep Width Range
Differential Decoder Enable
Descrambler Enable
BER Threshold
Demodulator Type
Data Inhibit
Group Link Address
Local Link Address
Demodulator Spectrum Rotation
LNB Power Low Current Threshold
LNB Power High Current Threshold
Reed-Solomon Decoder Enable
RX Reed-Solomon I Value
This command gives a status of each of the systems
configured by the commands covered in Section B.4 of this
remote document.
Modem
Options/
Misc
Information Command:
Response: <1/MOI_'cr'
>1/MOI_'cr'
s,SR'cr'
s,LRV'cr'
s,FRV'cr'
s,CARD_1_PCB'cr'
s,CARD_2_PCB'cr''lf']
(- or +) Single Code/data Rate
(- or +) Low Rate Variable
(- or +) Full Rate Variable
(x or +) Card #1 (DEMUX) Installed
(x or +) Card #2 (RS) Installed
Where: s = 0 (Not Installed or Upgraded), - (Not Installed,
FAST Upgradable), + (Installed). Or X (Not Installed, Field
Upgradable).
Card #1 Type
Information Command:
Response: <1/C1TI_'cr'
>1/C1TI_'cr'ttttt'cr''lf']
Where: ttttt = type (DEMUX_01, or Not _Installed).
Card #2 Type
Information
Command:
Response: <1/C2TI_'cr'
>1/C2TI_'cr’ttttt'cr''lf']
(Reed-Solomon)
Where: ttttt = type (RS_03 or NOT_INSTALLED)
Card #1
Options/
Misc
Information Command:
Response: <1/C1OI_'cr'
>1/C1OI_'cr''lf']
DEMUX_01 List:
s,4_CHAN'cr'
s,8_CHAN'cr'
Where: s = 0 (Not_Installed) or + (Installed).
Note: Card #1 installed only.
Card #2
Options/
Misc
Information
Command:
Response: <1/C2OI_'cr'
<1/C2OI_'cr''lf']
(Reed-Solomon)
Where: s = - (Not Installed, FAST Upgradeable) or
+ (Installed).
RS_03 list: s, INTELSAT’cr’’lf’] (- or +).
Note: Card #2 installed only.
Serial
Number Command:
Response: <1/SNUM_'cr'
>1/SNUM_'cr'
MODEM xxxxxxxxx'cr''lf']
CARD_1_xxxxxxxxx'cr''lf'] (Note 1)
CARD_2_xxxxxxxxx'cr''lf'] (Note 2)
Where: xxxxxxxxx = Serial number 000000000 to
999999999.
Notes:
1. Data is returned only if Card #1 is installed.
2. Data is returned only if Card #2 is installed.
A–9
