SDR-54A Satellite Demodulator Revision 4
Fully Accessible System Topology (FAST) MN/SDR54A.IOM
configuration of the available hardware. The access code can be purchased at any time
from Comtech Ef Data. Once obtained, the access code is loaded into the unit through the
front panel keyboard or the rear remote port.
With the exclusive FAST technology, operators have maximum flexibility for enabling
functions, as they are required. FAST allows an operator to order a modem precisely
tailored for the initial application, reducing risk and cost overruns during the application
integration process.
7.3 Implementation
FAST is factory-implemented in the modem at the time of order. Hardware options for
basic modems can be ordered and installed either at the factory or in the field. The
operator can select options that can be activated easily in the field, depending on the
current hardware configuration of the modem.
7.3.1 Activation Procedure
1. Obtain Demodulator serial number as follows:
a. Establish a connection to M&C REMOTE port.
b. [ENTER] <1/SNUM_'cr'
c. Record the following serial numbers as follows.
• Record Modem Serial Number: ______________.
• Record Card #1 Serial Number: ______________.
• Record Card #2 Serial number: _______________.
d. [ENTER]
Single Rate [ ] Card #1 [ ]
Low Rate Variable [ ] Card #2 [ ]
Full Rate Variable [ ]
7–2
