SDR-54A Satellite Demodulator

Revision 4

Reed-Solomon Option

MN/SDR54A.IOM

6.7.2 Interface Connector

Connector type 72-pin simm.

Table 6-4. Interface Connector

Pin #

Signal

Description

1 to 4, 69 to 72

GND

Ground

5 to 8, 65 to 68

+5V

+5V

9 to 11

Spare 0-2

NC

12 to 15

RS_SPR3-6

Spares from FPGA

16, 17

Spare 3, 4

NC

18

TXDAT

NC (Pull up)

19

TXCLK

NC (Pull up)

20 to 22

Spare 5-7

NC

23 SCT_OUT

NC

24 Spare

8

NC

25

DEC_DAT

(RS) Data to Main

26

DEC_CLK

(RS) Clock from Main

27

RS_DAT

RX Data from Main

28

RS_CLK

RX Clock from Main

29 Spare

9

NC

30 /TRS_EN

NC

31

/RS_CS

RS Chip Select

32 Spare

10

NC

33

SDA

IIC Port Expander Data

34

SCL

IIC Port Expander Clock

35 Spare

11

NC

36 to 43

BAD[0..7]

M&C Address/Data Bus

44 Spare

12

NC

45

BALE

M&C Buffer ALE

46

/BRD

M&C Buffer Read

47

/BWR

M&C Buffer Write

48 Spare

13

NC

49

RSXLX_CLK

25 MHz Clock RS Xilinx

50 Spare

14

NC

51

AHA_CLK

25 MHz Clock RS Decoder

52 RS_SPR7

NC

53 RI_SP

NC

54 RR_SP

NC

55 RT_SP

NC

56 RS_SPR8

NC

57 to 59

TXPA0-TXPA2

NC

60 RS_SPR9

NC

61 to 63

RXPA0-RX_PA2

ID

64 RS_SPR10

NC

6–9
