Digital Monitoring Products XR2500F Installation Guide
24
InstallatIon
Dry Contact Relay Outputs
17.1 Description
The XR2500F panel provides two programmable auxiliary SPDT relays with the two DMP Model 305 relays in
K6 (Output 1) and K7 (Output 2) and a Model 431 Output Harness on the J2 6-pin Header. Each relay provides
one SPDT set of contacts that can be operated by any of the functions listed below:
1) Activation by zone condition: Steady, Pulsing, Momentary, and Follow
2) Activation by 24-hour 7-day schedule: One on and one off time a day for each relay
3) Manual activation from the Security Command keypad menu
4) Communication failure
5) Armed area annunciation
6) Fire Alarm, Fire Trouble, or Supervisory
7) Ambush Alarm
8) Exit and Entry timers
9) System Ready
10) Late to Close
Refer to the XR500 Series Programming Guide (LT-0679) for specific information.
17.2 Contact Rating
The Model 305 relay contacts are rated for 1 Amp at 30 VDC (allows .35 power factor). Connect auxiliary
power to the Relay Output 1 common terminal by installing the gray harness wire to terminal 7. Current
draw for all connected devices must not exceed the panel maximum current rating.
17.3 Output Harness Wiring
The Output Harness is pre-installed on the 6-pin header labeled J2. Output 2 uses the top three prongs,
and Output 1 uses the bottom three prongs. Outputs 1 and 2 are pre-wired to the 866 NAC modules located
within the XR2500F enclosure. For reference, the wire harness and contact locations are shown below:
Contact Color
Output 1 normally closed Violet
Output 1 common Gray
Output 1 normally open Orange
Output 2 normally closed Blue
Output 2 common White
Output 2 normally open Yellow
