Section 3 Auto-Zone Basic
3-18 Programming
Setpoint Screen #3
Minimum Default Maximum
Cool Staging 1 Min 4 Min 30 Min
Min Cool Off 1 Min 4 Min 30 Min
Heat Staging 1 Min 4 Min 30 Min
Min Heat Off 1 Min 4 Min 30 Min
Setpoint Screen #4
Minimum Default Maximum
Interval 1 Min 10 Min 30 Min
Setpoint Screen #5
Minimum Default Maximum
Closed Volts 0.0 VDC 0.0 VDC 10.0 VDC
Opened Volts 0.0 VDC 10.0 VDC 10.0 VDC
The heating and cooling stages must have been off for a
minimum amount of time before they can be activated or re-
activated. As each additional stage of heating or cooling is
added, a minimum Staging Delay period must be satisfied
between each additional stage required.
Cool Staging: 4 Min
Min Cool Off: 4 Min
Heat Staging: 4 Min
Min Heat Off: 4 Min
If the Zone Manager needs to change HVAC modes
between heating and cooling, a Changeover Delay time
must be satisfied first. This prevents "chasing" due to
alternate hot and cold air always being supplied to the
zones after short intervals.
Manager Setpoints
Heat/Cool Changeover
Interval....: 15 Min
If the Zone Manager has been configured for Economizer
Control, this screen will appear. You can set the voltages
required to open and closed the damper. Some actuators use a
2-10 VDC signal instead of 0-10 VDC.
If the system is not configured for Economizer Control, no
economizer setpoint screens will appear.
Economizer Setpoints
Closed Volts: 0.0
Opened Volts: 10.0
