Appendix C: Power Consumption
Appendix C: Power Consumption
Test Equipment/Tool
DUT#1: VMC1000 with 32GB mSATA
DUT#2: VMC1000 with 32GB mSATA and 3.5G WWAN module
Windows XP
Burn-in Software: Version 5.0
Test Condition
Room temperature
Power supply graduation: 12V 5A
Test Procedure:
1. Start of all function at DUT and measure power consumption.
2. Get system into suspend mode and measure power consumption.
Unit
Idle Mode
100% Burn-in Mode
S3
S4
S5
DUT#1
1.3A
1.33A
148mA
12mA
12mA
DUT#2
1.33A
1.35A
72mA
56.7mA
56.7mA
* Device: N/A
