Appendix A: I/O Address Function
Startup and Shutdown Voltage Control
I/O port : 0EE8H
Bit3~2 Input Voltage
11 12V
01 24V
10 6~36V
00 6~36V
Delay Off Time Setting
Bit 2~0 Time (sec)
000 20 sec
001 1 min
010 5 min
011 10 min
100 30 min
101 1 hour
110 6 hour
111 18 hour
Delay On Time Setting
Bit5~6 Function Description
000 10 sec
001 30 sec
010 1 min
011 5 min
100 10 min
101 15 min
110 30 min
111 1 hour
Only set by switch on motherboard(read only)
Bit1~0 Input Voltage 12V
00 Startup Shutdown
11.5V 10.5V
01 Startup Shutdown
12V 11V
10 Startup Shutdown
12.5V 11V
11 Startup Shutdown
12.5V 11.5V
When input voltage 12V
I/O port : 0EE7H
Bit7: Power On Delay
0: DISABLE(*)
1: ENABLE
Bit6: Power Off Delay
0: DISABLE(*)
1: ENABLE
