8-1
8.1 Technical details
8 Technical details
8 8000 Technical details Technical details 8- 8.1 Technical details 8100 Technical details 8- ][Technische Daten PSSu XB XR CB
Technische Daten_Satz Normen
Technical details
Application range Standard/Failsafe
Support in system environment A
from FS firmware version for other head modules 1
from ST firmware version for other head modules 1
from FS firmware version PSSu H F PN 1
from ST firmware version PSSu H S PN 1
from ST firmware version PSSu WR S IDN 1
Support in system environment B
from head module FS firmware version 1.2.0
from head module ST firmware version 1.2.0
Electrical data
Internal supply voltage (module supply)
Supply voltage range of module supply
4.8 - 5.4 V
Module's current consumption 20 mA
Module's power consumption 0.10 W
Environmental data
Ambient temperature in accordance withEN 60068-2-14
-40 - 70 °C
Storage temperature in accordance with EN 60068-2-1/-2 -40 - 70 °C
Climatic suitability
EN 60068-2-14, EN 60068-2-1, EN 60068-2-2,
EN 60068-2-30, EN 60068-2-78
Climatic suitability in accordance with EN 60068-2-30,
EN 60068-2-78 93 % r. h. at 40 °C
Condensation yes
Max. operating height above sea level 5000 m
EMC EN 61000-4-2, EN 61000-4-3, EN 61000-4-4,
EN 61000-4-5, EN 61000-4-6
Vibration to EN 60068-2-6
Frequency
10 - 150 Hz
Max. acceleration 1g
Shock stress
EN 60068-2-27
15g
11 ms
EN 60068-2-29 10g
16 ms
Protection type in accordance with EN 60529
Mounting (e.g. cabinet)
IP54
Housing IP20
Airgap creepage in accordance with EN 60664-1,
EN 61131-2
Overvoltage category
II
Pollution degree 2
Mechanical data
Housing material
Front
PC
Bottom PC
Dimensions
Height
125.6 mm
Width 50.2 mm
Depth 72.6 mm
Weight 90 g
