7-1
7.1 Messages
7 Operation
7 7000 Operation Operation 7- 7.1 Messages 7100 Messages 7- ][BA_Betrieb Störung LED "Err" Sys A + B
A module error is displayed via the "Err" LED (see section entitled "Dis-
play elements"), signalled to the head module and then entered in the
head module's
 Error stack, with PSSu in system environment A
 Diagnostic log, with PSSu in system environment B.
][BA_Betrieb Fehler ST Relais
The module can detect the following errors:
(
1
) There are two levels of overtemperature.
 Too warm:
If a module's temperature exceeds a theshold value, the module
sends a warning to the head module. If the temperature drops back
below the threshold value, the module sends an all-clear.
 Too hot:
If a module's temperature exceeds a further theshold value, the mod-
ule sends an error message to the head module and switches off the
relay outputs.
 After the "too hot" message has been received, if the temperature
drops back below the "too warm" theshold value, the relay contacts
will close if the head module has set the status of the outputs to "1".
Further information on PSSu error messages is available in the online
help for the PSSuniversal Assistant system software.
Error Explanation Remedy
Start-up error Error as the PSSu system starts up. Change faulty module.
Configuration error Incorrect module type configured. The configured hardware registry does
not match the actual hardware regis-
try.
ST communication error Error in ST communication with the
head module. Change faulty module.
Bus termination error There is no end bracket. Install a terminating plate with inte-
grated end angle.
Temperature error: too warm (
1
) Ambient temperature too high:
Error stack entry Ensure there is sufficient ventilation in
the control cabinet or prevent over-
load.
Temperature error: too hot (
1
) Ambient temperature too high:
Relay outputs are switched off Ensure there is sufficient ventilation in
the control cabinet or prevent over-
load.
