Technical details
Operating Manual PSSu E F 4DI(­T)(­R)
21310­EN­05 30
8 Technical details
General 312200 314200 315200
Approvals BG, CE, GOST, TÜV,
cULus Listed BG, CE, GOST, TÜV,
cULus Listed
CE, TÜV
Application range Failsafe Failsafe Failsafe
Module's device code 0A00h 0A00h 0A00h
Number of FS input bits 4 4 4
Application in system en­
vironment A
From FS firmware ver­
sion, other head mod­
ules
4 4 –
From FS firmware ver­
sion PSSu H F PN
1 1 –
Application in system en­
vironment B
From FS firmware ver­
sion, head modules
1.0.0 1.0.0 1.5.0
Electrical data 312200 314200 315200
Internal supply voltage
(module supply)
Supply voltage range
of module supply
4,8 ­ 5,4 V 4,8 ­ 5,4 V 4,8 ­ 5,4 V
Module's current con­
sumption
23 mA 23 mA 23 mA
Module's power con­
sumption
0,12 W 0,12 W 0,12 W
Periphery's supply voltage
(periphery supply)
Voltage range 16,8 ­ 30,0 V 16,8 ­ 30,0 V 16,8 ­ 30,0 V
Module's current con­
sumption with no load
8 mA 8 mA 8 mA
Module's power con­
sumption with no load
0,19 W 0,19 W 0,19 W
Max. power dissipation of
module
1,50 W 1,50 W 1,50 W
Inputs 312200 314200 315200
Number 4 4 4
Number 4 4 4
Voltage at inputs 24 V DC 24 V DC 24 V DC
Input current at rated
voltage
6 mA 6 mA 6 mA
Input current range 2,6 ­ 7,8 mA 2,6 ­ 7,8 mA 2,6 ­ 7,8 mA
Min. threshold voltage
when signal changes from
"1" to "0"
9,0 V 9,0 V 9,0 V
Max. threshold voltage
when signal changes from
"0" to "1"
10,0 V 10,0 V 10,0 V
