Tecnical details
Operating Manual PNOZ m ES ETH
1002700­EN­04 20
Environmental data 772130
Shock stress
In accordance with the standard EN 60068­2­27
Acceleration 15g
Duration 11 ms
Max. operating height above sea level 2000 m
Airgap creepage
In accordance with the standard EN 61131­2
Overvoltage category II
Pollution degree 2
Rated insulation voltage 30 V
Protection type
In accordance with the standard EN 60529
Mounting area (e.g. control cabinet) IP54
Housing IP20
Terminals IP20
Mechanical data 772130
Mounting position Horizontal on top hat rail
DIN rail
Top hat rail 35 x 7,5 EN 50022
Recess width 27 mm
Max. cable length
Max. cable length per input 0,1 km
Material
Bottom PC
Front PC
Top PC
Dimensions
Height 101,4 mm
Width 22,5 mm
Depth 111,0 mm
Weight 80 g
The standards current on 2012­04 apply.
