Commissioning
Operating Manual PNOZ m ES ETH
1002700­EN­04 15
6.4.4 RJ45 connection cable
RJ45 connector
8­pin
8
1
10BaseT cable or 100BaseTX cable
max. 100 m
NOTICE
With the plug­in connection please note that the data cable and connector
have a limited mechanical load capacity. Appropriate design measures
should be used to ensure that the plug­in connection is insensitive to in­
creased mechanical stress (e.g. through shock, vibration). Such measures
include fixed routing with strain relief, for example.
