Tecnical details
Operating Manual PNOZ m ES ETH
1002700­EN­04 19
8 Tecnical details
General 772130
Approvals CCC, CE, GOST, cULus Listed
Application range Standard
Module's device code 1202h
Electrical data 772130
Supply voltage
for Module supply
internal Via base unit
Voltage 5,0 V
Kind DC
Voltage tolerance ­2 %/+2 %
Current consumption 295 mA
Power consumption 1,0 W
Status indicator LED
Ethernet interface 772130
Number 2
IP address (automatically off) 169.254.60.1
Connection type RJ45
Transmission rate 10 MBit/s, 100 MBit/s
Fieldbus interface 772130
Fieldbus interface Modbus TCP
Unit type Slave
Connection RJ45
Galvanic isolation Yes
Environmental data 772130
Ambient temperature
In accordance with the standard EN 60068­2­14
Temperature range 0 ­ 60 °C
Forced convection in control cabinet off 55 °C
Storage temperature
In accordance with the standard EN 60068­2­1/­2
Temperature range ­25 ­ 70 °C
Climatic suitability
In accordance with the standard EN 60068­2­30, EN 60068­2­78
Condensation during operation Not permitted
EMC EN 61131­2
Vibration
In accordance with the standard EN 60068­2­6
Frequency 10,0 ­ 150,0 Hz
Acceleration 1g
