7-1
7.1 Messages
7 Operation
7 7000 Operation Operation 7- 7.1 Messages 7100 Messages 7- Betrieb_Meldungen_allgemein_BA
When the supply voltage is switched on, the PNOZmulti safety system
copies the configuration from the chip card.
The LEDs "POWER","DIAG", "FAULT", "IFAULT" and "OFAULT" light up
on the base unit.
Betrieb_Meldungen_Feldbus_CANopen
The expansion module PNOZ mc6p/mc6.1p is configured and started
automatically. The LEDs “RUN” and “ERR” display the status of the
PNOZ mc6p/mc6.1p on CANopen.
7.1.1 Display elements for device diagnostics
Display elements for device diagnostics 7- Anzeige Legende 3x
Legend:
Betrieb_Anzeige_Feldbus_CANopen_BA
LED on
LED flashes
LED off
LED Meaning
PWR Supply voltage is present
Supply voltage is not present
RUN PNOZ mc6p/mc6.1p in "Operational" status
PNOZ mc6p/mc6.1p in "Stopped" status
PNOZ mc6p/mc6.1p in "Pre-Operational" status
No supply voltage or module error detected
ERR CAN controller is in "Bus off" status
Error threshold value has been reached, the CAN controller has received too many error
telegrams
Monitoring error, activation of master-slave monitoring error, e.g. heartbeat monitoring
Error in "Synchronisation" status, a synchronisation telegram, e.g. to write simultane-
ously on several devices, did not occur within the configured time
No error
1
1
2
3
