PZE X4VP
Operating Manual PZE X4VP
1003202­EN­08 14
Relay outputs 787580 787581 787582 787583
Max. short circuit
current IK
1 kA 1 kA 1 kA 1 kA
Utilisation category
In accordance
with the standard EN 60947­4­1
EN 60947­4­1 EN 60947­4­1 EN 60947­4­1
Safety­contacts,
delayed, AC1 at
240 V 240 V 240 V 240 V
Min. current 0,01 A 0,01 A 0,01 A 0,01 A
Max. current 6,0 A 6,0 A 6,0 A 6,0 A
Max. power 1500 VA 1500 VA 1500 VA 1500 VA
Safety­contacts,
delayed, DC1 at
24 V 24 V 24 V 24 V
Min. current 0,01 A 0,01 A 0,01 A 0,01 A
Max. current 6,0 A 6,0 A 6,0 A 6,0 A
Max. power 150 W 150 W 150 W 150 W
Utilisation category
In accordance
with the standard EN 60947­5­1
EN 60947­5­1 EN 60947­5­1 EN 60947­5­1
Safety contacts,
delayed AC15 at
230 V 230 V 230 V 230 V
Max. current 3,0 A 3,0 A 3,0 A 3,0 A
Safety contacts
delayed DC13 (6
cycles/min) at
24 V 24 V 24 V 24 V
Max. current 4,0 A 4,0 A 4,0 A 4,0 A
Utilisation category
in accordance with
UL
Voltage 250 V AC G.U.
(same polarity) 250 V AC G.U.
(same polarity) 250 V AC G.U.
(same polarity) 250 V AC G.U.
(same polarity)
With current 6,0 A 6,0 A 6,0 A 6,0 A
Voltage 24 V DC G. U. 24 V DC G. U. 24 V DC G. U. 24 V DC G. U.
With current 6,0 A 6,0 A 6,0 A 6,0 A
Pilot Duty B300, R300 B300, R300 B300, R300 B300, R300
Contact fuse protec­
tion external, safety
contacts
In accordance
with the standard EN 60947­5­1
EN 60947­5­1 EN 60947­5­1 EN 60947­5­1
