Determining
mining
mining
mining
mining
Effective Resolution
Effective Resolution
Effective Resolution
Effective Resolution
Effective Resolution
and Range
and Range
and Range
and Range
and Range
The effective resolution for an input channel depends upon the filter
frequency selected for that channel. The following tables provide the
effective resolution for each of the range selections at the six available
frequencies. The tables do not include the affects of unfiltered input noise.
Choose the frequency that most closely matches your requirements.
Table 4.6a Effective Resolution(In counts) vs. Input Filter
Selection
Input Type
60Hz
50Hz
10Hz
250Hz
500Hz
1000Hz
4to20mA
1
2
1
8
33
201
0to20mA
1
1
1
12
33
268
-10V to +10V
0
0
0
3
6
48
0to10V
1
0
1
2
16
96
1to5V
1
1
0
3
21
80
0to5V
1
1
0
5
16
65
-100mV to +100mV
1
1
1
14
40
160
-50mV to +50mV
2
1
1
13
46
61
Type J-TC
4
4
2
35
71
209
Type K-TC
12
7
6
58
162
761
Type T-TC
63
72
41
548
863
2036
Type E-TC
8
8
5
34
123
625
Type R-TC
14
18
11
120
365
1104
Type S-TC
17
16
6
112
381
928
Type B-TC
31
28
17
175
805
1633
Type N-TC
5
7
3
39
102
319
Type C-TC
6
6
3
60
162
341
100 Pt 385
3
2
1
17
51
408
200 Pt 385
1
0
1
7
16
93
500 Pt 385
1
0
0
3
57
514
1000 Pt 385
1
1
0
3
10
332
100 Pt 3916
3
2
1
26
21
684
200 Pt 3916
1
2
1
12
20
156
500 Pt 3916
1
1
0
6
83
453
1000 Pt 3916
0
1
0
7
24
63
10 Cu 426
50
40
14
149
206
1647
120 Ni 618
2
3
1
30
21
518
120 Ni 672
2
2
1
23
27
261
604 NiFe 518
1
1
0
10
35
631
150 ohm
5
5
2
20
107
1372
1000 ohm
1
2
1
7
39
102
3000 ohm
1
0
0
10
21
68
Note: A 1000 samples were taken to find the deviations listed above.
Raw/Proportional Counts
