Appendix A: Module Specifications 73
resistance imbalance. The hardware and software errors include
calibration of the system, and non-linearity of the ADC. For the sake of
the calculations the resolution of the ADC was assumed to be at least 16
bits (use of the 10Hz, 50Hz, and 60Hz filter frequencies). Note: The
250Hz frequency should not be applied to thermocouple or RTD inputs if
accuracy is a concern.
Input Type Error @ 25C Error over temp
typical & worst case typical & worst case
Platinum 385 100 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Platinum 385 200 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Platinum 385 500 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Platinum 385 1000 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Platinum 3916 100 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Platinum 3916 200 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Platinum 3916 500 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Platinum 3916 1000 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Nickel 618 120 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Nickel 618 200 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Nickel 618 500 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Nickel 618 1000 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Nickel 672 120 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Nickel-Fe 518 604 ohm 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Cu 427 10 ohm 0.5%FS , 1.0%FS 1.0% FS, 2.0% FS
Resistance Input, 0-250 ohms 0.05% FS, 0.1% FS 0.25% FS, 0.5% FS
Resistance Input, 0-500 ohms 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Resistance Input, 0-1000 ohms 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Resistance Input, 0-2000 ohms 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Resistance Input, 0-3000 ohms 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Resistance Input, 0-4000 ohms 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Input Type Error @ 25C Error over temp
typical & worst case typical & worst case
Type J, -210 to 1200C 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Type K, -225 to 1370C 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Type K, -270 to -225C 0.3% FS, 0.6% FS 0.6% FS, 1.2% FS
Type T, -230 to 400C 0.05% FS, 0.1% FS 0.25% FS, 0.5% FS
Type T, -270 to -230C 0.5% FS, 1.25% FS 1.25% FS, 2.5% FS
Type E, -220 to 1000C 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Type E, -270 to -220C 0.25% FS, 0.5% FS 0.5% FS, 1.0% FS
Type R, 0 to 1768C 0.06% FS, 0.12% FS 0.12% FS, 0.25% FS
Type S, 0 to 1768C 0.06% FS, 0.12% FS 0.12% FS, 0.25% FS
Type B, 600 to 1820C 0.09% FS, 0.18% FS 0.25% FS, 0.5% FS
Type B, 300 to 600C 0.11% FS, 0.22% FS 0.5% FS, 1.0% FS
Type N, -200 to 1300C 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
Type N, -210 to 200C 0.07% FS, 0.14% FS 0.14% FS, 0.28% FS
Type C, 0 to 2315C 0.05% FS, 0.1% FS 0.1% FS, 0.25% FS
