Pitney Bowes DI600 Inserting System - Manual (Page 112)

7 • Reference
7-8 SV40221 Rev. C
Changing the Envelope Sealer Unit Felts
The sealer unit felts are supplied as part of a kit and can be changed
by the operator in the following way:
1. Hinge open the Sealer
Bottle cover located at the
front right hand side of
the machine. Remove the
Sealer Bottle.
2. Remove the Insert Trays
(see page 5-9).
Lift the insertion area
plastic cover and open the
envelope exit area access
door.
3. Squeeze together the two
blue tabs (A) and lift the
blue tab (B) to gain access
to the sealer unit felts.
A A
A B
