7 • Reference
7-6 SV40221 Rev. C
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT
NOTIFICATION AND ARE SUBJECT TO TEST
Envelope Sealer
The machine can seal up to a maximum of 3,000 envelopes between
refills.
Drop Stacker
The Drop Stacker can accommodate up to 150 Mail Pieces.
(This is dependent on the size and contents of the envelope).
Material Requirements
For best performance, use only materials approved by your machine
supplier.
Materials should be good quality and properly stored.
Recommended
storage conditions: 65°F (18°C) to 77°F (25°C)
40% to 60% relative humidity
Min 1" (25.5mm)
Max 2-1/2" (63mm)
Min 1/4" (6mm)
Max 1-5/8" (41mm)
3/4" (19mm)
Min 1/16" (1.6mm)
Max 1/4" (6mm)
throat depth
at 3/4" (19mm)
in from edge of
envelope
Closed flap tip should not
come closer than
1-3/4" (44mm) to bottom
of envelope
Envelope Feeder (continued)
Envelope flap and throat requirements:
