Troubleshooting • 6
6-13 SV40221 Rev. C
Access to the Removable Paper Path
(under Insert Feeder F)
This removable plate is located immediately below Insert Feeder
F. Therefore, before access can be gained to a material stall in this
area, Insert Tray F must be removed as described on page 6-9.
Access can be gained by
lifting the blue handle and then
pulling the plate outwards.
When refitting the plate, make
sure it is fully latched into
position.
Access to the Top Cover (Sheet Feed Area)
Access can be gained to this
area by unlatching the blue
handle on the Top Cover and
raising the cover.
When closing the cover, make
sure it is fully latched into
position.
