Parts Lists & Drawings
P a r r I n s t r u m e n t C o m p a n y 74
Parts List for A1284DD2 Stirrer Hub Assembly
Item Description
1282DD Hub, Stirrer
1283DD2 Shaft, Stirrer
1242DD3 Pulley, Timing
682DD Snap Ring, Internal .50
683DD Wave Spring, .50 OD
684DD Ball Bearing
A540DD Stirrer Assembly
1288DD Coupler, Stirrer Shaft
1242DD3F Set Screw, Pulley
Parts List for Water Tank Assembly
Item Description
1301DD Water Tank, 6200
386VB Nipple, 1/2 NPT, Nylon
413VB Cap, 1/2 NPT, Nylon
387VB Elbow, 1/2” NPT, Plastic
1020DD Plug Cap
271HWHJ Hose Barb, Male, 1/2T – 1/2NPTM
Parts List for Cooling Water Supply
Item Description
328VB Union, Bulkhead 1/4 Tube
196VB Valve, Brass, 1/4 Tube
343VB Port Connector, 1/4 Tube, Brass
A1276DD Cold Water Solenoid Assembly w/
connectors
Parts List for Oxygen Filling System
Item Description
244VB Union Bulkhead, 1/8 Tube
A476A3 Slip Connector w / 1/8 NPT
438VB Elbow, 45 °, 1/8 NPT x 1/8 Tube
HX0012TB024 High Pressure Tube, 1/8, Nylon
180VB Male Elbow 1/8 T x 1/8 NPTM
527VB Restrictor 0.012 – 1/8 NPT
A1278DD Oxygen Solenoid Assembly
697HC2 Filter Sintered Bronze
243VB2 Male Connector, 1/8 T x 1/8 NPT
394HCJE O-Ring EP 3/8 ID X 1/16 CS
Part List for 6200 Stirrer Motor and Drive
Item Description
1285DD Mount, Motor, 6200
1241DD2 Belt Timing, 6200
1242DD Pulley Timing, 6200
A1268DD Motor, Stirrer, 6200
Spare and Installation Parts List*
Item Description
20VB Valve Seat
230A O-Ring, Bomb Head, 2-3/8 ID
238A O-Ring, 3/16 ID
394HCJE O-Ring, 3/8 ID
415A O-Ring, 7/16 ID
3415 Benzoic Acid Pellets, 1 g, 100 pcs
421A Bomb Lifter
43AS Sample Capsule, SS
475A Service Clamp Head
A719E Cordset 115V
A719EEE Cordset 230V
HJ0025TB035 Tube, Nylon ¼ OD
TX03SKMM Metric Hex Wrench, 0.89 mm
A570DD Oxygen Regulator
143AC Insulator, Delrin
388A Spacer
401A Sleeve Insulator
96AC Electrode Insulator
378A Packing Cap
PA1332RD04 G-32 x 1/4 RHMS
A38A Head Support and Stand
840DD2 Heat Wire
845DD2 Ignition Thread
A391DD Oval Bucket
1889E Display Protection Film
1344DD LCD Stylus
Note: Parts may change depending on which
bomb was ordered with the calorimeter.
