Parts Lists & Drawings
6200 F
w w w . p a r r i n s t . c o m 73
a
PPendix
f
Parts Lists & Drawings
Principal Assemblies in Calorimeter
Item Description
1108P Oxygen Combustion Vessel
A391DD Oval Bucket
A570DD Regulator Assembly, Oxygen
A1279DD2 Controller Assembly
A1311DDEB Pump Assembly, Circulating, 115V
A1311DDEE Pump Assembly, Circulating, 230V
A1268DD Motor Assembly, Pump, 12V
A1276DD Cold Water Solenoid
A1284DD Stirrer Hub Assembly
A297E Lead Wire
A1278DD Oxygen Solenoid, w/o fittings
1940E Power Supply
897E Capacitor, 40V, 81000 uF
1317DD Lid Seal
1417E2 Thermistor Bucket
538VB Male Connector 1/8 NPTM-T-BT
Nylon
549DD Gas Spring
139E23 Fuse Fast/ Act 15 Amp 250V
1641E Pump Fuse (F1), Fast-Act, 1 Amp,
250VAC
1641E2 Heater Fuse (F2), Fast-Act, 2.5
Amps, 250VAC
Caution!
For continued protection against possible
hazard, replace fuses with same type and
rating of fuse.
Parts List for A1279DD2 Controller Assembly
Item Description
1926E Film Guard, LCD 1802E
SA1332RD04 6-32 x 1/4 RHMS 18-8 SS
SA1140RD08 4-40 x 1/2 RHMS 18-8 SS
A1821E Speaker Assembly with Cable
A1822E Power Cable Assembly
A1823E Touchscreen Cable Assembly, 12”
A2140E Board, I/O
A2141E LCD Transition Board
A2163E Cable, LCD
A2164E Cable, Backlight Control
A2166E Cable, I/O to CPU USB
A2167E Cable, USB Peripheral Cable
1477DD Gasket, Display Kyrocer/Hantronix
2147E LCD
1472DD LCD Encasement - Kyrocera
A2154E2 CPU Board 6200
Parts List for Temperature Control Assembly
Item Description
1281DD Manifold, Temperature Control
1417E Thermistor, Jacket
538VB Male Connector, 1/8 NPTM-T-BT
Nylon
252HWHJ Elbow, Hose Barb, 1/2 x 3/8 M
280HWHJ Elbow, Hose Barb, 1/4 T X3/8 M
A1275DDEB Cartridge, Heater Assembly 120V
A1275DDEE Cartridge, Heater Assembly 240V
535VB Male Connector, 1/4T x 3/8 NPTM
A92HWBB Male Connector, 1/4T x 1/8 NPTM
283VB Adapter, Male 1/4T x 1/8 NPTM
A1276DD Cold Water Solenoid Assembly w/
connector
117HW3 Elbow, Male, 1/4T x 1/8 NPTM
2040E Thermostat, Manual Reset
