Figure 2-5, Open loop configuration with 1552, Installation – Parr Instrument 6200 User Manual
Page 16
2
Installation
P a r r I n s t r u m e n t C o m p a n y
14
Figure 2-5
Open Loop Configuration with 1552
O2 Regulator
Line 3
Tap Water
· >27 °C
Line 1
~27 °C
Line 2
1552
Water
Cooler
Drain
Line 1 & 2 – Maximum length of 10 feet, 1/4” OD, Polyurethane (Part Number HJ0025TB035)
Line 3 – Maximum length of 25 feet, 1/8” OD, Nylon (Part Number HX0012TB024)
