English- 5
+ -
Please use br ake unit and/or
brake resi stor depending on
type and appli cati on
Brake unit
(optional)
BUE
BR
brake resis tor
(opti onal)
F ig ure 1 f or mo dels o f VFD- E Series
VF D002E11A/21A/23A, VF D004E11A/21A/23A/43A, VFD007E21A/23A/43A,
VF D015E23A/43A, V FD002E11C/21C/23C, VFD004E11C/21C/23C/43C,
VF D007E21C/23C/43C, VFD015E23C/43C, VF D002E 11P/21P /23P,
VF D004E11P /21P/23P/43P, VFD007E21P/23P /43P, VF D015E23P/43P
Please use br ak e unit and/or
brake resis tor depending on
type and applic ation
+/B1
-
brake resis tor
(opti onal)
BR
B2
Figure 2 fo r mo dels of VFD-E Series
VF D007E11A, V FD015E21A, V FD022E21A/23A/43A, VF D037E23A/43A,
VF D055E23A/43A, V FD075E 23A/43A, VFD110E43A, VF D007E11C,
VF D015E21C, VF D022E21C/23C/43C, VFD037E23C/43C,
VF D055E23C/43C, V FD075E 23C/43C, VFD110E43C
Please use brake resistor
depending on type and
application
Figure 3 for models of VFD-E Series
VFD002E11T/21T/23T, VFD004E11A/21T/23T/43T,
VFD007E21T/23T/43T, VFD015E23T/43T
B2
BR
brake resistor
(optional)
Figure 4 Wiring for NPN Mode and PNP Mode
A. NPN mode without external power B. NPN mode with external power
Factory
setting
NPN
PNP
Factory
setting
NPN
PNP
24
Vdc
-
+
