Delta Electronics AC Motor Drives VFD-XXXE User Manual
Page 12
English- 12
Pr.
Explanation
Settings
Factory
Setting
NOTE
00.12
50Hz Base Voltage
Selection
0: 230V/400V
1: 220V/380V
0
Group 1 Basic Parameters
01.00
Maximum Output
Frequency (Fmax)
50.00 to 600.0 Hz
60.00
01.01
Maximum Voltage
Frequency (Fbase)
(Motor 0)
0.10 to 600.0 Hz
60.00
220.0
01.02
Maximum Output
Voltage (Vmax)
(Motor 0)
115V/230V series: 0.1V to 255.0V
460V series: 0.1V to 510.0V
440.0
01.03
Mid-Point Frequency
(Fmid) (Motor 0)
0.10 to 600.0 Hz
1.50
10.0
01.04
Mid-Point Voltage
(Vmid) (Motor 0)
115V/230V series: 0.1V to 255.0V
460V series: 0.1V to 510.0V
20.0
01.05
Minimum Output
Frequency (Fmin)
(Motor 0)
0.10 to 600.0 Hz
1.50
10.0
01.06
Minimum Output
Voltage (Vmin)
(Motor 0)
115V/230V series: 0.1V to 255.0V
460V series: 0.1V to 510.0V
20.0
01.07
Output Frequency
Upper Limit
0.1 to 120.0%
110.0
01.08
Output Frequency
Lower Limit
0.0 to100.0 %
0.0
a
01.09
Accel Time 1
0.1 to 600.0 / 0.01 to 600.0 sec
10.0
a
01.10
Decel Time 1
0.1 to 600.0 / 0.01 to 600.0 sec
10.0
0.1 to 600.0 / 0.01 to 600.0 sec
10.0
a
01.11
Accel Time 2
For VFD*E*C models, the factory setting is 1.0
0.1 to 600.0 / 0.01 to 600.0 sec
10.0
a
01.12
Decel Time 2
For VFD*E*C models, the factory setting is 1.0
a
01.13
Jog Acceleration
Time
0.1 to 600.0 / 0.01 to 600.0 sec
1.0
a
01.14
Jog Deceleration
Time
0.1 to 600.0 / 0.01 to 600.0 sec
1.0
a
01.15
Jog Frequency
0.10 Hz to Fmax (Pr.01.00) Hz
6.00
01.16
Auto acceleration /
deceleration (refer
to Accel/Decel time
setting)
0: Linear Accel/Decel
1: Auto Accel, Linear Decel
2: Linear Accel, Auto Decel
3: Auto Accel/Decel (Set by load)
4: Auto Accel/Decel (set by Accel/Decel
Time setting)
0
01.17
Acceleration S-
Curve
0.0 to 10.0 / 0.00 to 10.00 sec
0.0
01.18
Deceleration S-
Curve
0.0 to 10.0 / 0.00 to 10.00 sec
0.0
01.19
Accel/Decel Time
Unit
0: Unit: 0.1 sec
1: Unit: 0.01 sec
0
01.20
Delay Time at 0Hz
for Simple Position
0.00 to 600.00 sec
0.00
