Pr. Explanation Settings
Factory
Setting
NOTE
12.18
Max. ACI3 Input
Current
0.0 to 20.0mA 20.0
12.19
Max. ACI3 Scale
Percentage
0.0 to 100.0% 100.0
12.20
AO1 Terminal
Analog Signal Mode
0: AVO1
1: ACO1 (analog current 0.0 to 20.0mA)
2: ACO1 (analog current 4.0 to 20.0mA)
0
0: Analog Frequency
12.21
AO1 Analog Output
Signal
1: Analog Current (0 to 250% rated current)
0
12.22
AO1 Analog Output
Gain
1 to 200% 100
0: AVO2
1: ACO2 (analog current 0.0 to 20.0mA)
12.23
AO2 Terminal
Analog Signal Mode
2: ACO2 (analog current 4.0 to 20.0mA)
0
0: Analog Frequency
12.24
AO2 Analog Output
Signal
1: Analog Current (0 to 250% rated current)
0
12.25
AO2 Analog Output
Gain
1 to 200% 100
Group 13: PG function Parameters for Extension Card
13.00 PG Input
0: Disabled
1: Single phase
2: Forward/Counterclockwise rotation
3: Reverse/Clockwise rotation
0
13.01 PG Pulse Range 1 to 20000 600
13.02
Motor Pole Number
(Motor 0)
2 to 10 4
a 13.03
Proportional Gain
(P)
0.0 to 10.0 1.0
a 13.04 Integral Gain (I) 0.00 to 100.00 sec 1.00
a 13.05
Speed Control
Output Frequency
Limit
0.00 to 100.00Hz 10.00
a 13.06
Speed Feedback
Display Filter
0 to 9999 (*2ms) 500
a 13.07
Detection Time for
Feedback Signal
Fault
0.0: disabled
0.1 to 10.0 sec
1
0: Warn and RAMP to stop
1: Warn and COAST to stop
a 13.08
Treatment of the
Feedback Signal
Fault
2: Warn and keep operation
1
a 13.09
Speed Feedback
Filter
0 to 9999 (*2ms) 16
0: PG card
13.10
Source of the High-
speed Counter
1: PLC (NOT for VFD*E*C models)
Read
Only
