Page 56
56
When the searching is in work, the message “Searching
Records” is displayed.
The search result could be:
• “No records found” meaning that no records were found
with specified criteria.
• “No records stored” meaning that there is no record in log.
• Display the log.
The records will have the following structure:
1 - Time of the record
2 – Chlorine value
3 – pH value (only for PCA 320 and PCA 330)
4 – Alarm field (empty if no alarms)
5 – Errors field (empty if no errors)
The double arrow sign is present on the bottom line if the log
continues outside the display.
Pressing “UP” or “DOWN” arrow key, scroll the log with one
record up or down. Pressing longer time one of those keys will
scroll with one page at a time (4 records).
Pressing “CFM” when a record is highlighted, the record con-
tent will be displayed in details.
The display contains:
1 – The log day
2 – The log hour and minute
3 – The chlorine concentration and units (mg/l)
4 – The pH value and units (pH)
5 – The ORP value and units (mV)
14:38 1.00
5.86
14:33 1.05
5.63 A
14:27 1.20
4.99
E
14:22 1.17
5.11 AE
1
2
3
4
5
Temp. Out of Range>
2004/01/19 06:13
0.33 mg/L
5.85 pH
205 mV
5.0 ºC
1
2
4
6
3
5
7
