One row with messages is also displayed.
When the display
show one of this pan-
els, pressing “CFM”,
will enter in the pan-
els related to the pa-
rameter displayed in
the left side.
Example: When pH is displayed on the left side and the chlorine, ORP
and temperature on the right side, pressing “CFM” will go in
one of the pH measure panels.
MEASURE PANELS
For each parameter, several measure panels are available.
One panel contains large digits for better visibility.
The measure panels contains:
1 = the measured value (chlorine, pH, ORP or temperature)
2 = the measurement units (mg/L, pH, mV, °C or °F)
3 = the current time in format HH:MM
4 = error or alarm indicator
5 = information about the operating mode.
6 = warnings, alarms and errors, displayed one at a time
7 = the last row displays less important information:
• Maximum and minimum value
• Sampling time
• Reagent doses left
• Alarm High and Alarm Low
• Regulator Setpoint and Delta or Hysteresis
• Analog output maximum and minimum
• Cl measuring phase
STANDBY 16:35
1.35 mg/L Alarm
Min:0.00
Max5.00
3 1 2
6
7
5
4
08:10
6.29 pH Error
< Low ORP >
Min:4.18 Max:7.00
