Hanna Instruments HI 84529 - Manual (Page 49)

www. hannainst .com 49 Specifications
Temperature
Range -20.0 to 120.0°C (-4.0 to 248.0°F)
Resolution 0.1°C
Accuracy ±0.4°C without probe error
Additional Specifications
pH Electrode FC 260B pH electrode with 1 m (3.3’) cable (included),
Reference Electrode HI 5315 reference probe with 1 m (3.3’) cable (included)
Temperature Probe
HI 7662-M stainless steel temperature probe with 1 m (3.3’)
cable (included)
Environment 0 to 50°C (32 to 122°F); RH max 95% non-condensing
Power Supply 12 VDC adapter (included)
Dimensions 235 x 200 x 150 mm (9.2 x 7.9 x 5.9”)
Weight 1.9 kg (67.0 oz.)
Specifications
Titrator
Range
(Low Range): %l.a.: 0.01 to 0.20; ºSH: 0.4 to 8.9; ºD: 1.0 to
20.0; ºTH: 1.1 to 22.2
(High Range): %l.a.: 0.1 to 2.0; ºSH: 4.4 to 88.9; ºD: 10 to 200;
ºTH: 11.1 to 222.2
Resolution
(Low Range): %l.a.: 0.01; ºSH: 0.1; ºD: 0.1; ºTH: 0.1
(High Range): %l.a.: 0.1; ºSH: 0.1; ºD: 1; ºTH: 0.1
Accuracy (@25ºC/77ºF) (Low Range): ± 0.01 %l.a. (High Range): ± 0.1 %l.a.
Method Acid-base titration
Principle Endpoint titration, 8.30 pH adjustable pH 8.1 - 8.4
Sample Size LR 20 20 mL or 20 g
Sample Size LR 50 50 mL or 50 g
Sample Size HR 20 20 mL or 20 g
Pump speed 10 mL/min
Stirring Speed 800 (Low Range) / 1000 (High Range)
Logging Data up to 200 samples (pH or mV)
pH Meter
Range -2.0 to 16.0 pH / -2.00 to 16.00 pH
Resolution 0.1 pH / 0.01 pH
Accuracy (@25ºC/77ºF) ±0.01 pH
Calibration
one, two or three-point calibration (pH 4.01, 6.00, 8.30,
10.01)
Temperature Compensation manual or automatic from -20 to 120°C (-4 to 248°F)
Logging Data up to 50 samples
mV Meter
Range -2000.0 to 2000.0 mV
Resolution 0.1 mV
Accuracy ± 1.0 mV
