PC INTERFACE
Data transmission from the instrument to the PC can be done with the HI 92000 Windows ® compatible
software (optional). HI 92000 also offers graphing and on-line help feature.
Data can be exported to the most popular spreadsheet programs for further analysis.
HI 4211 and HI 4212 instruments have two available serial interfaces: RS232 and USB. The desired serial
interface can be selected from the settings window of the HI 92000 software.
If choosing the RS232 serial interface, use the optional Hanna HI 920010 cable connector to connect your
instrument to a PC. Make sure that your instrument is switched off and then plug one connector to the
instrument RS232 socket and the other one to the serial port of your PC.
Note: Other cables than HI 920010 may use a different configuration. In this case, communication between
instrument and PC may not be possible.
If choosing the USB serial interface, use a standard USB cable to connect your instrument to the PC.
For both serial interfaces, make sure that the instrument and the HI 92000 software have the same baud rate
and the appropriate communication port.
To delete lots:
• Press
while in Log Recall mode.
• Press or to access delete or delete all mode.
Otherwise, press to return to Log Recall view mode.
• After selecting one of the deleting modes, use or
to select one lot and then press or
to delete the selected lot or all lots. The “Please wait...”
message will be displayed on the LCD until the selected lot or
all lots are deleted.
• Press and then press to exit deleting mode
and return to Log Recall view mode.
• Press to exit Log Recall mode and return to Measure
mode.
Note: Logged lots should also be deleted whenever “Please Delete Old Log Files” or “Low Data Logging Space”
message appears on the LCD, in the Reminder messages area.
