4.11 Create Graphic
 Select “Graphic” in left side of screen, and then click the icon for Graphic creating
 Move cursor to the location where the “Graphic” will be creating, and press left key of mouse then.
 In the Graphic dialog, select “Graphic Source” will pop up a sub-dialog to load graphic/image from either -
file, clipboard or a downloaded graphic.
Select the downloaded graphic in printer, user can choose where the Graphic going to come from - “General” or
“Database”
 General: it select “Graphic”, user can define the text stream of Graphic with serial number, variable, data
and time.
 Database: There are six databases (SQL, Access, Oracle, Excel, Txt, DBF) can be adopting when user
selected database in the dialog. In fact, it also can be created by the icon “Database Query” in
“Generic Tool Set”.
 The detail of how to define serial number, variable and database, please refer to both paragraphs
“Variable and Serial Number” and “Database” in the chapters 5.2 to 5.5
 To remove/delete the printer’s saved “Graphic”, please go on the “Advance Tool Set”, which has an icon
“Delete Printer Object”
