Page 21: 9 create a barcode
GoLabel On-line Help
21
V1.002f
4.9
Create a Barcode
4.9.1
Create 1D Barcode
1) Symbology
Select “Barcode” in the left side of screen, and then click the icon
of the “Object Too Set”, and move
cursor to the location that “1D Barcode” will be located and click left key again.
There are four sub-dialogs in the “Barcode Setup” – Symbology, Human Readable Style, Font and Data
Source
In the Symbology sub-dialog, choose barcode type first and then define its Height, Narrow, Width, and
Width/Narrow Ratio. Be sure to design a corrective barcode for scanner reading.
The barcode also can be rotated from 0, 90, 180- and 270 degree. A field of “Bar Code Data” may key-in
by users themselves.
After the completed of definition the Barcode, please click “Refresh Preview” to preview the designing
Barcode, or press “Enter Key” while you key-in the data to the field of “Bar Code Data”
There are many documents on the web or book story can be reference if someone is no idea how to
design the 1D barcode.
