GoLabel On-line Help

V1.002f

4.10.5 Drawing Circle or Ellipse



Select “Shape” in left side of screen, and then click the icon

for circle/ellipse drawing



Move cursor to the location where the first point of circle/ellipse will be drawing, press left key of
mouse and drag it to end point and release it then.



The object’s location, width and height are movable and adjustable by the dragging while user
presses the left key of mouse on the object when it’s being selected.



Double click to the circle/ellipse that will pop up a “Setup” dialog for the width, height, thickness, fill
pattern and brush color editing
