- OPTIONAL EQUIPMENT - WIRELESS REMOTE
The Wireless Remote transmitter FOB allows remote operation of the VPL, from a suitable location.
The Wireless Remote option can be used in conjunction with the Call/Send Control option.
Additional FOB transmitters are available.
Multiple FOB transmitters allow VPL operation from
various locations, for instance from a dry warm vehicle or from the comfort of your home.
Do not allow unauthorized persons to use the VPL or the VPL Wireless Remote transmitter FOB.
WIRELESS REMOTE COMPONENT LIST:
FIG. 5.1
FIG. 5.2
To prevent unwanted electrical discharge, always
turn off VPL power, unplug VPL AC power cord, and
unplug White ground wire from battery before installing antenna.
FIG. 5.2 shows the Gama Receiver mounting location. Place the receiver on VPL lower rail as shown. Hold
receiver steadily and insert a marker into the holes where the two #8-32 Thread Cutting Screws will go and
mark the VPL frame.
