Page 303
xDSL Application
Copper and xDSL Tests
295
Title Bar
Title Bar
The Title Bar displays the software application name and the battery level
indicator.
Test Information and Control
The xDSL application allows you to connect and synchronize to DSL
circuits and networks, configure xDSL tests and system parameters, export
and view previously saved results.
Start/Stop button. For more details, see Start/Stop Button on page 307.
Open
icon allows you to select and open a previously saved result
file.
Save
icon allows you to save the current test results.
Clear
icon resets the current test results to their initial settings, in
the xDSL Test application.
Report
icon opens a separate page where you can input
information describing the saved test results, Create a report from the
current measure, save it, and Display report after creation.
