19 xdsl application, Using the graphical user interface – EXFO FTB-635 Wideband Copper and DSL Test Module User Manual
Page 301
Copper and xDSL Tests
293
19 xDSL Application
Using the Graphical User Interface
This chapter describes the graphical user interface of your xDSL tests
application. The graphical user interface allows you to configure and start
the DSL tests, view results and statistics, and other information related to
the FTB-635.
The Application user interface contains:
Main window
Status bar
Title bar
Test information and control
Main menu
Application buttons
Title Bar
Main Menu
Main
Window
Status Bar
Application
Buttons
Test
Information
and Control
