EXFO FTB-2 User Manual
Page 43
Getting Started with Your Unit
FTB-2 and FTB-2 Pro
33
Inserting and Removing Test Modules
To remove a module from the FTB-2 or FTB-2 Pro:
1. Turn off your unit.
2. Position the unit so that its right panel is facing you.
3. Turn one locking screw counterclockwise until you can remove it
completely.
4. Remove the three remaining screws in the same way.
Turn locking screw
counterclockwise
