Using Your Unit and Modules in an Automated Test Environment
FTB-2 and FTB-2 Pro
251
Monitoring Remote Commands
If monitoring using TCP/IP, which provides sending SCPI
commands over TCP/IP through Telnet from the EXFO Instrument
Control, you are automatically connected to the monitoring
system.
Note: Port 5024 is designated for sending SCPI commands in the Telnet protocol.
Once connected, your current connection information will appear
in the All Connections View tab, and the commands will appear as
a list in the lower part of the window.
The Disconnect button becomes available for you to click when
you are ready to disconnect.
Connection information is also displayed in a separate tab,
identified by its IP address, from where you can monitor the
commands and other actions sent through TCP/IP over Telnet, as
well as the results.
Connection
tabs
List of
connections
