Fiber Inspection Probe 65
B Fiber Inspection Probe Tip
Compatibility Chart
The table below establishes the Fiber Inspection Probe tip compatibility
with the different fiber inspection and the analysis (option) modules
provided with the ConnectorMax application:
Tip Description Tip Code Inspection Analysis
Uni.1.25 mm tip for PC connector FIPT-400-U12M X X
LC tip for PC bulkhead adapter FIPT-400-LC X X
FC and SC APC tip for bulkhead adapter FIPT-400-FC-SC-APC X X
Uni.2.5 mm tip for APC connector FIPT-400-U25MA X X
Uni.1.25 mm tip for APC connector FIPT-400-U12MA X X
ST tip for UPC bulkhead adapter FIPT-400-ST X X
FC and SC tip for bulkhead adapter FIPT-400-FC-SC X X
Uni.2.5 mm tip for PC connector FIPT-400-U25M X X
Extended SC tip for PC bulkhead
adapter
FIPT-400-SC-L X X
MU tip for UPC bulkhead adapter FIPT-400-MU X X
E-2000 tip for PC bulkhead FIPT-400-E2000 X X
MU-L tip for UPC bulkhead adapter FIPT-400-MU-L X X
Tip for D4 bulkhead adapter FIPT-400-D4 X X
U20M2 tip for male ferule connector FIPT-400-U20M2 X X
LEMO tip for bulkhead adapter FIPT-400-LEMO X X
E-2000 tip for APC bulkhead adapter FIPT-400-E2000-APC X
OPTITAP tip for APC bulkhead adapter FIPT-400-OTAP-APC X
OPTITIP MT tip kit for APC bulkhead
adapter
FIPT-400-OTIP-MT-APC X
