Inspecting Fiber Ends
Fiber Inspection Probe 39
Saving Files
Saving Files
In capture mode, you can save the acquisition files manually for future
reference.
If you have purchased the analysis option you can also set ConnectorMax
so that it saves the capture automatically regardless of the result, or
automatically when the result is Pass only.
Note: When you return to the live mode, your file name structure will be
automatically incremented so that you do not overwrite your work.
Note: In multiple-fiber connector mode, the option is set automatically to Manual
and you cannot change it.
To save files automatically or automatically when the status is set
to Pass:
1. From the main window, select User Preferences.
2. Select the General tab.
3. Select whether you want the capture to be automatically saved
regardless of the result, saved if the result of the analysis is pass, or
select the manual save option if you only want to save specific files.
4. If you want to change the default location where the files will be saved,
you can do so by using the button.
5. Click Apply to confirm your choice and continue working in the
window, or OK to confirm your choice and close the window.
