EXFO FIP-400 Fiber Inspection Probe and ConnectorMax User Manual
Page 48
Inspecting Fiber Ends
42
FIP-400
Analyzing Captures (Optional, Single-Fiber Connector Mode Only)
Analyzing Captures (Optional, Single-Fiber
Connector Mode Only)
If you have acquired the capture analysis tool, it will be available in
ConnectorMax for you to perform automated pass/fail analyses according
to the criteria you have set.
The analysis option enables all of the tabs in the viewing area, whereas the
inspection-only option only enables the Image and Identification tabs.
Note: On units that allow it (FTB-500, FTB-200 v2), you will notice that the
Pass/Fail LED will indicate the analysis result as you capture files.
To enable the analysis tool:
1. From the main window, select User Preferences.
2. Under the General tab, select Analyze on capture.
