Fiber Inspection Probe 13
3 Setting up Your Fiber
Inspection Probe and
ConnectorMax
You can change various settings in ConnectorMax such as the brightness
and contrast levels, default storage location, or automated file name. These
settings are stored for each user and kept for future work sessions.
Changing the Fiber Inspection Probe Tip
You can use various tips depending on the type of connector you are
inspecting. For more information about tips you can use, visit the EXFO
Web site at
www.exfo.com .
To change a tip:
1. Untighten the tip’s retaining nut.
2. Remove the tip.
3. Insert a new tip.
4. Adjust the tip to the notch.
5. Retighten the retaining nut.
