Connectormax software – EXFO FIP-400 Fiber Inspection Probe and ConnectorMax User Manual
Page 12
Introducing the FIP-400 Fiber Inspection Probe and ConnectorMax
6
FIP-400
ConnectorMax Software
ConnectorMax Software
ConnectorMax is the application used to view the fiber inspections. If you
have purchased the corresponding option, you can also use specific test
configurations and analyze the fibers automatically upon capturing a
picture.
Button bar
Viewing
area
File name preview (Capture
mode) or current test
configuration (Live mode)
Current (Capture
mode) or next (Live
mode) fiber index
Focus indicator
Probe
connection
status
Inspection
and analysis
tabs
Capture/Live
mode
button
